Oil Hose,Fabric Insert Oil Hose,Fuel hose
Russia Standard : ГОСТ 18698-79 --- Б(I)
Applications : For gasoline, kerosene, mineral oils, petroleum-based
Temperature range : -30 ℃ to +70 ℃
|
Диаметр(внутр.), мм |
Диамет(наружн.) мм |
Давление,МПа | Класс | Длина, м | |||||
| ID мм | OD(mm) |
Pressure Mpa |
Type | Length (m) | |||||
| 12 | 23 | 0.3;0.6;0.8;1.0 | Б | 10; 20 | |||||
| 16 | 27 | 0.3;0.6;0.8;1.0 | Б | 10; 20 | |||||
| 18 | 29 | 0.3;0.6;0.8;1.0 | Б | 10; 20 | |||||
| 20 | 31 | 0.3;0.6;0.8;1.0 | Б | 10; 20 | |||||
| 25 | 38 | 0.3;0.6;0.8;1.0 | Б | 10; 20 | |||||
| 32 | 43 | 0.3;0.6;0.8;1.0 | Б | 10; 20 | |||||
| 38 | 49 | 0.3;0.6;0.8;1.0 | Б | 10; 20 | |||||
| 50 | 62 | 0.3;0.6;0.8;1.0 | Б | 10; 20 | |||||
| 65 | 77 | 0.3;0.6;0.8;1.0 | Б | 9.5; 10 | |||||
| 75 | 87 | 0.3;0.6;0.8;1.0 | Б | 9.5; 10 | |||||
| 100 | 111 | 0.3;0.6;0.8;1.0 | Б | 4;10 | |||||
| 125 | 136 | 0.3;0.6;0.8;1.0 | Б | 4;10 | |||||
| 150 | 161 | 0.3;0.6;0.8;1.0 | Б | 4;10 | |||||
| 200 | 213 | 0.3;0.6;0.8;1.0 | Б | 4;10 |
