High fexibility timing belt in car

High fexibility timing belt in car

Product Details

 High fexibility timing belt in car

Features of Rubber Timing Belt :

Construction:

1 Top Sufface: wear resistant chloroprene rubber compound

2 Tenson glass fiber

3 Base: shear resistant chloroprene rubber compound

4 Cover nylon cover

Benefits:

* High efficiency factor and Extreme tensile strength

* Extraordinarily resistance on cold & and ozone

* Excellent aging-resistance and abrasion-resistance



       * Slip-free transmission and low noise

Technical data of Rubber timing belt :



Type

Pitch

Tooth height

Belt thickness

Type

Pitch

Tooth height

Belt thickness

R(MR)

9.525

3.54

5.69

ZB

9.525

2.29

4.50

Y(MY)

8.00

3.06

5.21

ZH

9.525

3.50

5.50

YU

8.00

3.05

5.30

ZR

9.525

3.20

5.40

RU

9.525

3.41

5.40

YA

8.00

2.95

5.20

ZA

9.525

1.91

4.10

FS

9.525

3.05

5.35

S8M

8.00

3.05

5.30

YR

8.00

2.00

5.10



Type

Tooth No.

R(MR)

68 70 78 89 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 123 124 125 129 130 133 134 135 136 138 141 148 149 150 151 153 157 158 163 177

Y(MY)

99 100 101 103 106 107 108 111 112 113 116 117 121 123 124 127 128 129 131 137 143 144 145 146 147 159 168 169 177 178 191 211

YU

65 69 76 83 95 99 100 101 103 104 015 106 107 108 109 110 111 112 113 116 117 121 123 125 130 131 132 133 135 140 141 142 143 145 146 147 153 154 155 156 159 164 165 167 168 173 177 179 187 191 193 195 197 201 207 210 211 21 9223 226 228 232 234 251 257 259 265 281

RU

58 59 70 73 76 79 82 83 85 88 89 91 92 93 94 95 97 98 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 116 117 118 119 120 122 123 124 125 126 127 129 130 131 132 133 134 135 136 142 145 146 148 149 151 152 153 154 157 158 159 163 173 176 177 197

ZA

54 55 63 58 59 76 79 80 83 84 85 87 88 89 90 91 92 93 94 95 97 98 99 102 103 104 106 108 109 110 111 115 116 117 120 121 122 123 124 129 127 133 139 142 144 146

S8M

58 65 91 95 106 109 110 112 123 130 132 133 135 137 138 140 141 142 144 145 146 148 149 150 151 152 153 160 162 163 164 168 169 171 173 175 179 191 192 193 209 211 220 222 225 239 253 281

ZB

87 119 123 130 134 135 136 137 143 149
